Nuova Fima EN837.1 ürününü Türkiye 'den Satın Alın

DMU-S-D-DIVERS

Pressure sensor Type: 08.S18 Execution: pressure sensor with ceramic cell Accuracy: 0,5% F.S.V acc. to IEC 60770-Limit point Electrical connection: Male and female plug DIN 43650 Specification Code acc. to Data-sheet 08 = Electronics S18 = Pressure transmitter 0-600 bar = range 43M = process connection: 1/2 NPT male 10E = output: 4-20 mA, 2 wire / supply: 10..30 VDC Please check the process connection and output. It was not specified in the inquiry.

DRUMI-D-000266

Statistische Warennummer: 90262040 Pressure transmitter with local readout for homogenizer Type: 08.MOM.3.A.E.AAFZ (0...400 bar).422.1. Filling liquid: dielectric oil Mounting: direct, bottom connection Dial diameter: 100 mm Process connection: SA422 Range: 0-400 bar case in st.st. AISI 304 glass window Output: 4-20 mA Power Supply: 10...30Vcc with logo "NUOVA FIMA" and "LR"

DRUMI-D-DIVERS

Pressure gauge Type: 1.20.3.A.E.41M. Execution: all st.st. bourdon tube pressure gauge Solid front execution, glycerine filled Mounting:direct dial diameter: DN 100 Range: 0-16 bar Case material: bayonet-lock case in st.st. AISI 304 window material: safety glass accuracy: Kl. 1,0 with diaphragm seal MGS 9/2B 4.2B0.9.9.43F.41F.BAI diaphragm in Hastelloy C276 process connecion in Hastelloy C276 process connection: 1/2" NPT female

DRUMI-D-DIVERS 08.MOM.1.A.E

(Pressure transmitter with local readout for homogenizer Mounting: direct, bottom connection Dial diameter: 100 mm Process connection: SA167 Range: 0-600 bar case in st.st. AISI 304 glass window Output: 4-20 mA Power Supply: 10...30Vcc with calibration certificate (C01))

E04400.0001

KAMERA

FM-KL01-D-000008 01.27.1.A.I

Statistische Warennummer: 90262040 Pressure gauge Type: 01.27.1.A.I Execution: Laboratory bourdon tube test gauge Mounting: direct Diameter: DN 250 (10") Connection: 1/2 NPT male bottom in st.st. AISI 316 Range: 0-40 bar Case material: Aluminium, black coated External zero-adjustment High precision movement mounted on ball bearing Dial: Anti-parallax mirror Pointer: balanced, antiparallax knife-edge micrometer, adjustable Window material: Plexiglas Accuracy: Kl. 0,1 Specials: factory test certificat, traceable to international Standard

FM-KL01-D-DIVERS

range 0-250 bar

GAUGE MODEL MGS 18

(version "all stainless steel": DN 63) 1.18.3.DC0/16 BAR.21M

GAUGE MODEL MGS 18 (VERSION "ALL STAINLESS STEEL": DN 63) 1.18.3.DC0/25 BAR.21M

KM-D-DIVERS

(Pressure gauge Type: 01.M2.3-D-E-0/400 bar-41M-04D.BM2.E Execution: all st.st. bourdon tube pressure gauge MCE18/3/E oil filled with double electric contact Mounting: with front flange diameter: DN 100 Connection: 1/2" BSP back in st.st. AISI 316L Range: 0-400 bar Case material: bayonet-lock case in st.st. AISI 304 window material: Plexiglas contacts: First contact opening, second contact opening on rising pressure, magnetic snap action)

MANO-ZUB-D-DIVERS

Over pressure protection MP 4/8A in st.st. AISI 316 5.48A.5.41M.41F setting: 3....15 psi process connection : 1/2" BSP male gauge connection: 1/2" BSP female

MGS18 1.18.2.A.E-.AAFB.43M.C40.T32

basınç göstergesi

MGS18 DN100-150

1.18.3.A.E.---.DAE7.41M.KCS ALL ST. ST. PRESSURE GAUGE, MODEL MGS18. 4" (100 MM) CASE DIAMETER. BOTTOM CONNECTION., RANGE 0...6 BAR/PSI, 1/2" BSP MALE PROCESS CONNECTION, ALUMINIUM DIAL, WHITE BACKGROUND WITH BLACK MARKINGS AND FIGURES, ST. ST. CASE AND BAYONET RING, DIRECT MOUNTING, ST. ST. PRECISION MOVEMENT, BLACK ALUMINIUM POINTER, ACCURACY ±1,0%, GLYCERINE FILLING, IP67 PROTECTION DEGREE, TEMPERED GLASS WINDOW, ST.ST. RESTRICTOR, MOUNTING WITH DIAPHRAGM SEAL

MP5-22

A 106 GR B carbon steel process connection 1/2" BSP male gauge connection: 1/2" BSP female

RHH1 VD U180

o. 3/20800420/10 Flow: 23,000 Nm3 H: 760 mbar

TB+143 350 700 M.65

Thermometer, ½” Q: 100 0-150

TB899 (6.TB8.9.9.F.ATFT.43M.7)

BİMETALİK TERMOMETRE

TB-HW-D-899

(Thermometer Type: 06.TB.899.G.43M.8.300.T01 Execution: all st.st. bimetal thermometer Mounting: every angle stem diameter: DN 150 (6") Stem: 300 x 8mm in st.st. AISI 316 Connection: 1/2" NPT male in st.st. AISI 316L sliding male swivel nut Range: 0/ 100°C Case material: bayonet-lock case in st.st. AISI 304 window material: glass accuracy: Kl. 1,0 tropicalization)

TB-HW-D-899 / 06.TB.899.G.43M.S8.430

(Execution: all st.st. bimetal thermometer Mounting: every angle stem diameter: DN 150 (6") Stem: 430 x 8mm in st.st. AISI 316 Connection: 1/2" NPT male in st.st. AISI 316L sliding male swivel nut Range: -50 / +50°C (nearest available range) Case material: bayonet-lock case in st.st. AISI 304 window material: glass accuracy: Kl. 1,0)

TB-HW-D-DIVERS 6.TB.819

Thermometer Type: 6.TB.819.E.43M.8.170.0/100°C. Execution: all st.st. bimetal thermometer Mounting: lower connection Diameter: DN 100 Stem: 8 x 170mm in st.st. AISI 316 Connection: 1/2" NPT in st.st. AISI 316L sliding male swivel nut Range: 0/100°C Case material: bayonet-lock case in st.st. AISI 304 window material: glass accuracy: Kl. 1,0

TYPE 03.30.AAFV.A.1.23F.

Pressure switch 1 microswitch Type A, single standard setting range: 6-250 bar cable exit: 1/2" BSP female UNI 6125 process connection: 1/4" NPT female

MGS18. 4" (100 MM)

183.1.100.0100.0 Pressure gauge

183.1.100.0250.0 Pressure gauge

20 2 A E + 40 500 Pressure Gauge

010-063-D-DIVERS

MANOMETRE

STMA M27X1.5

verici

8.SMA.AAFV.41M.1.FPM (DMU-S-D-000865)

çalkalama diyafram basınç iletici
