| Marka | Nuova Fima |
| Ürün | 39GCR30CP501 |
| Tanım | basınç göstergesi |
| Sipariş kodu | OZH4059050 |
Nuova Fima 39GCR30CP501'nın üstün kalitesini ve performansını Özhat İç ve Dış Tic. Ltd. Şti. ile Türkiye'de keşfedin. Güvenilirlik veya verimlilik arıyorsanız, bu ürün tüm endüstriyel ihtiyaçlarınızı karşılar.
39GCR30CP501, çeşitli uygulamalarda optimal performans ve dayanıklılık sağlamak için tasarlanmıştır. Yüksek kaliteli yapısı ve yenilikçi özellikleri ile profesyonellerin tercihidir.
39GCR30CP501'nin Ana Özellikleri:
Özhat İç ve Dış Tic. Ltd. Şti. ile 39GCR30CP501'yi rekabetçi fiyatlarla ve en hızlı teslimat süreleri ile Türkiye genelinde sunuyoruz. Uzman ekibimiz, tüm sorularınızla size yardımcı olmaya ve özel çözümler sunmaya hazırdır.
Neden Özhat İç ve Dış Tic. Ltd. Şti.?
Lütfen Nuova Fima ürünlerini tedarik etmemize rağmen, Özhat İç ve Dış Tic. Ltd. Şti.'ın yetkili bir distribütör olmadığını unutmayın. Tüm haklar üreticilere ve resmi ortaklarına aittir.
Bugün Teklif Alın! 39GCR30CP501 ile operasyonlarınızı geliştirmeye hazır mısınız? Kişiselleştirilmiş teklif için şimdi bizimle iletişime geçin. Aşağıdaki formu doldurun veya talebinizi e-posta ile gönderin. İşletmeniz için maliyet etkin, kaliteli bir seçim yapmanıza yardımcı olalım.
Önemli Not: Nuova Fima ürünlerini tedarik etmemize rağmen, Özhat İç ve Dış Tic. Ltd. Şti. yetkili bir distribütör değildir. Markanın tüm hakları üreticiler ve resmi ortaklarına aittir.
DDM-DM-D-DIVERS 02.16.1.A.G.0/600 mbar.43M.C.S31.R10
Statistische Warennummer: 90262040 Differential pressure gauge Type: 02.16.1.A.G.0/600 mbar.43M.C.S31.R10 Execution: with double diaphragm Mounting:direct or with back flange diameter: DN 150 Lower Connections: 1/2" NPT male in st.st. AISI 316L Range: 0- 600 mbar static pressure: max. 100 bar Case material: bayonet-lock case in st.st. AISI 304 window material: glass case filling: glycerine 2" Stackes bracket accuracy: Kl. 2,5 %
Statistische Warennummer: 90268020 Druckmessumformer Typ: 08.S18 NUOVA FIMA Code: 08.S18-0/40 bar-23M-1 Messbereich: 0-40 bar Ausgang: 4-20 mA, 2 Leiter Hilfsenergie: 8-30 VDC Genauigkeit: 0,5% FSO nach IEC 60770 Prozessanschl.: 1/4 NPT Aussengewinde Elektr. Anschluss: Steckverbindung DIN 43650 Schutzart: IP 65
DMU-S-D-001009 08.S18 08 / S18 AAFE = 0-16 BAR 23M 1 = OUTPUT: 4...20 MA- 2 WIRES , SUPPLY: 8...30
Pressure sensor Execution: pressure sensor with ceramic cell
Pressure sensor Type: 08.S18 Execution: pressure sensor with ceramic cell Accuracy: 0,5% F.S.V acc. to IEC 60770-Limit point Electrical connection: Male and female plug DIN 43650 Specification Code acc. to Data-sheet 08 = Electronics S18 = Pressure transmitter 0-600 bar = range 43M = process connection: 1/2 NPT male 10E = output: 4-20 mA, 2 wire / supply: 10..30 VDC Please check the process connection and output. It was not specified in the inquiry.
Statistische Warennummer: 90262040 Pressure transmitter with local readout for homogenizer Type: 08.MOM.3.A.E.AAFZ (0...400 bar).422.1. Filling liquid: dielectric oil Mounting: direct, bottom connection Dial diameter: 100 mm Process connection: SA422 Range: 0-400 bar case in st.st. AISI 304 glass window Output: 4-20 mA Power Supply: 10...30Vcc with logo "NUOVA FIMA" and "LR"
Pressure gauge Type: 1.20.3.A.E.41M. Execution: all st.st. bourdon tube pressure gauge Solid front execution, glycerine filled Mounting:direct dial diameter: DN 100 Range: 0-16 bar Case material: bayonet-lock case in st.st. AISI 304 window material: safety glass accuracy: Kl. 1,0 with diaphragm seal MGS 9/2B 4.2B0.9.9.43F.41F.BAI diaphragm in Hastelloy C276 process connecion in Hastelloy C276 process connection: 1/2" NPT female
(Pressure transmitter with local readout for homogenizer Mounting: direct, bottom connection Dial diameter: 100 mm Process connection: SA167 Range: 0-600 bar case in st.st. AISI 304 glass window Output: 4-20 mA Power Supply: 10...30Vcc with calibration certificate (C01))
KAMERA
Statistische Warennummer: 90262040 Pressure gauge Type: 01.27.1.A.I Execution: Laboratory bourdon tube test gauge Mounting: direct Diameter: DN 250 (10") Connection: 1/2 NPT male bottom in st.st. AISI 316 Range: 0-40 bar Case material: Aluminium, black coated External zero-adjustment High precision movement mounted on ball bearing Dial: Anti-parallax mirror Pointer: balanced, antiparallax knife-edge micrometer, adjustable Window material: Plexiglas Accuracy: Kl. 0,1 Specials: factory test certificat, traceable to international Standard
range 0-250 bar
(version "all stainless steel": DN 63) 1.18.3.DC0/16 BAR.21M
(Pressure gauge Type: 01.M2.3-D-E-0/400 bar-41M-04D.BM2.E Execution: all st.st. bourdon tube pressure gauge MCE18/3/E oil filled with double electric contact Mounting: with front flange diameter: DN 100 Connection: 1/2" BSP back in st.st. AISI 316L Range: 0-400 bar Case material: bayonet-lock case in st.st. AISI 304 window material: Plexiglas contacts: First contact opening, second contact opening on rising pressure, magnetic snap action)
Over pressure protection MP 4/8A in st.st. AISI 316 5.48A.5.41M.41F setting: 3....15 psi process connection : 1/2" BSP male gauge connection: 1/2" BSP female
MGS18 1.18.2.A.E-.AAFB.43M.C40.T32
basınç göstergesi
1.18.3.A.E.---.DAE7.41M.KCS ALL ST. ST. PRESSURE GAUGE, MODEL MGS18. 4" (100 MM) CASE DIAMETER. BOTTOM CONNECTION., RANGE 0...6 BAR/PSI, 1/2" BSP MALE PROCESS CONNECTION, ALUMINIUM DIAL, WHITE BACKGROUND WITH BLACK MARKINGS AND FIGURES, ST. ST. CASE AND BAYONET RING, DIRECT MOUNTING, ST. ST. PRECISION MOVEMENT, BLACK ALUMINIUM POINTER, ACCURACY ±1,0%, GLYCERINE FILLING, IP67 PROTECTION DEGREE, TEMPERED GLASS WINDOW, ST.ST. RESTRICTOR, MOUNTING WITH DIAPHRAGM SEAL
A 106 GR B carbon steel process connection 1/2" BSP male gauge connection: 1/2" BSP female
o. 3/20800420/10 Flow: 23,000 Nm3 H: 760 mbar
Thermometer, ½” Q: 100 0-150
TB899 (6.TB8.9.9.F.ATFT.43M.7)
BİMETALİK TERMOMETRE
(Thermometer Type: 06.TB.899.G.43M.8.300.T01 Execution: all st.st. bimetal thermometer Mounting: every angle stem diameter: DN 150 (6") Stem: 300 x 8mm in st.st. AISI 316 Connection: 1/2" NPT male in st.st. AISI 316L sliding male swivel nut Range: 0/ 100°C Case material: bayonet-lock case in st.st. AISI 304 window material: glass accuracy: Kl. 1,0 tropicalization)
TB-HW-D-899 / 06.TB.899.G.43M.S8.430
(Execution: all st.st. bimetal thermometer Mounting: every angle stem diameter: DN 150 (6") Stem: 430 x 8mm in st.st. AISI 316 Connection: 1/2" NPT male in st.st. AISI 316L sliding male swivel nut Range: -50 / +50°C (nearest available range) Case material: bayonet-lock case in st.st. AISI 304 window material: glass accuracy: Kl. 1,0)
Thermometer Type: 6.TB.819.E.43M.8.170.0/100°C. Execution: all st.st. bimetal thermometer Mounting: lower connection Diameter: DN 100 Stem: 8 x 170mm in st.st. AISI 316 Connection: 1/2" NPT in st.st. AISI 316L sliding male swivel nut Range: 0/100°C Case material: bayonet-lock case in st.st. AISI 304 window material: glass accuracy: Kl. 1,0
Pressure switch 1 microswitch Type A, single standard setting range: 6-250 bar cable exit: 1/2" BSP female UNI 6125 process connection: 1/4" NPT female
